Ground mounting systems - Stalex

At Procarte, we focus on delivering comprehensive solutions to support the implementation of photovoltaic projects. As an authorized distributor of Stalex ground-mount systems, we offer high-quality ground structures that combine installation simplicity with exceptional durability and corrosion resistance.
With our expertise and experience, we are equipped to meet the most demanding expectations of our customers, providing products that meet the highest quality standards.

2Vx4 Structure – Base Table

Base Table 2Vx4 is designed for mounting 8 photovoltaic modules. The structure is made from high-quality S355 steel and coated with Magnelis ZM310/430, providing long-term corrosion protection and stability in challenging ground conditions.

Additional Options

We also offer additional mounting components to expand the structure:

• Extension 2Vx2 – allows mounting of 4 additional modules.
• Extension 2Vx1 – allows mounting of 2 additional modules.

Each structure can be combined in any configuration, tailored to individual needs. The tables are connected with dedicated purlin connectors, detailed in the installation manual, including a 3D view.

Optional Stabilizing Elements

For more challenging ground conditions and specific requirements, we offer additional stabilizing elements:

• Leg Brace
• Rear Brace with Angle Iron

Advantages of Stalex Double-Support Ground Structure

• Affordable Shipping Costs – structures up to 20 kW are shipped for a fee of 400 PLN net.
  – 20-40 kW tables are shipped as two oversized pallets for a fee of 700 PLN net.
• Fast Order Fulfillment:
  – Structures are stocked, allowing for immediate order processing.
  – Delivery time is 2-3 business days. Important! The structure includes long components, so assistance with unloading is required.
• Warranty – 10-year warranty on all offered structures.

Technical Specifications:

• Structure: double-support, driven into the ground, made from high-quality S355 steel coated with Magnelis ZM310/430.
• Angle of Inclination: 30°, providing optimal alignment of photovoltaic panels.
• Module Layout: Configurable in a 2×4 layout, with extensions available – 2×5, 2×6, and more, adaptable to client requirements.
• Orientation: vertical, enabling efficient use of space.
• Number of Modules: 8, expandable with extensions.
• Embedment Depth: minimum 1.5 m, ensuring stability even in challenging ground conditions.

Documentation

• Catalog – Stalex Mounting Systems
• Technical Specifications – Stalex Structural Steel
• Technical and Operating Documentation
• Mounting Instructions
• 3D View

Important Information

Our structures are not designed for bifacial panels.

To complete the full mounting kit, additional elements such as mounting clamps, M8x30 hex bolts, spring washers, and M8 flange nuts are required.
